McLeod Racing
McLeod RXT Clutch Gm LS 1-1/8in X 26 Spline 6932-07
- SKU:
- mlr6932-07
- UPC:
- 887753011244
- MPN:
- 6932-07
- Condition:
- New
Frequently bought together:
Description
Part Number: mlr6932-07
Description: RXT CLUTCH, GM LS 1-1/8" X 26 SPLINE
Alignment Tool Included: Yes
Clutch Usage: Street/Track
Disc Material: Metallic
Disc Style: Solid Hub
Flywheel Included: No
Hardware Included: Yes
Horsepower Rating: 1000
Pilot Bushing Included: No
Pilot Bushing Material: N/A
Pressure Plate Style: Diaphragm
Spline: 1 1/8" x 26
Throwout Bearing Included: No
Throwout Bearing Style: Standard
Disc Material: Ceramic
Disc Style: Full Face/Multi Pad
NOTE:: Will only fit LS1/LS6 Flat style Flywheels. Will not fit LS2/LS3/LS7 recessed flywheels.
NOTE: 2: Will only fit 6.250" diameter crank relief on 1996-2017 Modular Ford flywheels.
NOTE: 3: Will not fit on 2012-Up Modular Ford Flywheels with 9 bolt Pressure Plate Pattern.
NOTE: 4: Will only fit Ford Applications with aftermarket transmissions with 1-1/8 x 26 spline.
Spline: 1 1/8In. x 26
NOTE: 2: Will only fit 6.250In. diameter crank relief on 1996-2017 Modular Ford flywheels.
Make: Chevrolet,Ford, Pontiac
Application 1: 1999-2017 Ford Mustang; 4.6L/5.0L/5.4L
Application 2: 1998-2015 Chevrolet Camaro; 5.7L/6.2L/7.0L
Application 3: 1997-2013 Chevrolet Corvette; 5.7L/6.0L/6.2L/7.0L
Application 4: 1998-2002 Pontiac Firebird; 5.7L
Application 5: 2004-2006 Pontiac GTO; 5.7L/6.0L
Make: Chevrolet, Ford, Pontiac
Clutch Usage: Performance
Disc Style: Segmented
Clutch Disc Quantity: 2
Disc Diameter (in.): 9.687
Input Shaft Diameter: 1.125
Input Spline Quantity: 26
Hub Style: Solid
Clutch Patterns: 11" GM LS-X With Dowel Pin; 11" Ford Modular with Dowel Pins
Flywheel Fitment: For use with Ford Modular/GM LS-X
Quantity: Sold as a kit.
Note: LS1/LS6 Flat Style Flywheels ONLY! Will NOT Work w/LS2/LS3/LS7 recessed flywheels. Will NOT fit Ford w/9 Bolt Pattern.
