COMP Cams .510in Lift Beehive Valve Spring Kit For GM Vortec Hydraulic Flat Tappets 26906VCS-KIT

Part Number: cca26906VCS-KIT Description: COMP Cams .510in Lift Beehive Valve Spring Kit For GM Vortec Hydraulic Flat Tappets Outside Diameter of Outer Spring (in): 1.087/1.292 Inside Diameter of Outer Spring (in): .645/.850 Inside Diameter of Inner Spring (in): N/A Spring Rate (lbs/in): 386 Damper Spring Included: No Maximum Coil Bind Height (in): 1.18 Valve Spring Finish: Raw Retainer Material: Chromoly Lock Style: 10 Degree Valve Stem Diameter (in): 11/32 Valve Stem Seal Type: Positive Stop Valve Stem Seal Material: Viton Integrated Spring Seat: No Spring Seat OD (in): N/A Spring Seat Step Diameter (in): N/A Machine Work Required: No Quantity: 16 California Proposition 65: WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov Coil Bind Height: 1.18 Installed Height: 1.75 Installed Pressure: 111 Open Pressure: 304 Spring Type: Beehive Valve Spring Style: Beehive Number of Springs Per Valve: 1 Installed Height (in): 1.75 Load at Installed Height (lbs): 111 Open Height (in): 1.25 Load at Open Height (lbs): 304 Recommended Max Lift (in): 0.51
