ACL Toyota 4AGE/4AGZE (1.6L) Standard Size High Performance w/ Extra Oil Clearance Rod Bearing Set 4B1780HX-STD

Part Number: acl4B1780HX-STD Description: Toyota 4A-GZE 1587cc Inline4 DOHC 4v Supercharged Min Std Tunnel Size: 1.7717"(45.000mm) Oil Clearance: + 0.001" Extra Size: Standard Max Overall Length: 0.673"(17.10mm) Max Std Shaft Size: 1.6535"(42.000mm) Max Wall at Crown: 0.0580"(1.474mm) Max Std Tunnel Size: 1.7726"(45.024mm) Min Std Shaft Size: 1.6529"(41.985mm) Grade Type: Performance Outside Diameter: 1.7717 Shaft Diameter: 1.653 Width: 17.1 Max Wall: 0.058
